Easy to use
KEY FEATURES
Movable
•Charger on wheels can be transported
•It can be operated anywhere
•The wheels can be fixed or removed
Safety and experience
• ≥IP54 Overall protection level
• 21-inch touch interactive screen
• 5 meters of charging cable
MAIN PARAMETERS
-
Movable DC FAST Charger
iMChargerX is a mobile DC fast charger and smart EV charging solution. It offers 60 kW of charging power for one, or 30 kW for two fast charging outlets simultaneously. GB/T, CCS1, CCS2, CHAdeMO, and NACS charging methods are supported. It is equipped with a user-friendly 21-inch touchscreen and RFID reader. The charging session can also be followed on a mobile phone. iMChargerX is suitable for charging all types of electric vehicles, cars, trucks, buses, marine and off-highway vehicles. You can easily charge electric vehicles at events, auto shops, bus and truck stops, boat ports, construction sites and mines. The upgraded version iMChargerX is equipped with a 40kwh energy storage system, which has a lower upfront investment cost and flexible non-permanent installation. Our version without batteries can achieve a maximum power of 80kw
- Offers 60 kW of charging power for one fast charging outlet, or 30 kW for two simultaneously
- Compatible with GB/T, CCS1, CCS2, CHAdeMO, and NACS charging methods
- Features a user-friendly 21-inch touchscreen for easy operation
- Monitor your charging session directly from your mobile phone
- Built-in 40kwh energy storage battery capacity
MAIN PARAMETERS
Category
ltem
Technical Parameters
Input AC power connection 3ph,125A Voltage range 400VAC±15% Input power 86KVA Input frequency
50~60Hz
Power factor
≥0.98
Efficiency
≥95%
Output
Max power 80kw
Max current 140A Output voltage range 200~1000V Basic Parameters Connentor type CCS1 CCS2 Gunline length 5m Ingress Rating ≥IP54 Cooling Forced air Operating temperature -30°C+55°
Humidity < 95% relative humidity HMI 10-inch touch screen Communication Protocol OCPP1.6J Dimensions 680*660*1450mm Weight 160KG Energy storage configuration parameter
Category
ltem
Technical Parameters
Input Single-phase charging power Max7KW@ AC200~300V Three-phase charging power Max20KW@AC380~480V DC Input Max power Max40KW Output Max charging power 30kw*2(Two gun)60kw(single gun) Letter of agreement OCPP1.6J DC charging range 200~750VDC Max output current 0~150A Batteries Battery Pack Capacity 40kwh Rated Battery Pack Voltage 657V Battery Pack Type Lithium-ion Battery General DC Connection Standard CCS1/CCS2 AC Connection standard Industrial Sockets DC Cable Length 5m Cooling Forced air Operation temperature -20°C~55°C Operational noise level <60dB Dimensions(L*W*H) 680*660*1650mm Weight 300KG User Interface Main switch, 21" touch screenemergency stop switch, chargestatus indication LED bars
Product Physical Display
Application scenario
